●符合RoSH环保                                                                                      有

●兼容性                                                  SATA1和SATA2.6

●闪存技术                                                Samsung SLC-NAND Flash

●样式                                                    标准的2.5英寸SATA硬盘

  ◆连接                                                   标准的7针数据线，15针电源线

●设置主盘/从盘跳线                                                                                无

●系统性能

  ◆数据传输方式                                           SATA1或者SATA2

  ◆数据传输速率                                           1.5Gb/s and 3.0Gb/s

  ◆连续读                                                 184.3MB/sec

  ◆连续写                                                 153.4MB/sec

  ◆平均访问时间                                           0.2ms(估计)

●环境指标

  ◆工作温度                                     STD. 0℃ ～ 70℃ /IND. -40℃ ～ +85℃

  ◆非工作温度                                   STD. -20℃ ～ +80℃ /IND. -50℃ ～ +95℃

  ◆湿度                                                   5% ～95%(无凝结)

  ◆噪声                                                   0db

  ◆抗震动                                                 16G

  ◆抗冲击                                                 1.500G

  ◆高度                                                    70.000M

●功耗

  ◆电压要求                                                              +5.0V±10% ;

  ◆读电流                                                                   320.0 mA(Max.);

  ◆写电流                                                                 360.0 mA(Max.);

  ◆休眠模式电流                                           160.0 mA(Max.);

●可靠性

  ◆MTBF（无故障工作时间）                                                  3.000.000 小时以上

  ◆纠错码                                                                 采用8bits or 15bits ECC Code

  ◆读写次数                                                                                             2.000.000次

  ◆数据可靠性                                      每读 10¹⁴ 比特出现不多于1次不可恢复的错误

  ◆数据保存期                                                                                        10年

●物理尺度

  ◆重量 (最大的)                                                                                     115.0 g (4.06 oz )

  ◆尺寸(宽*长*高)                                                                                   69.90mm *99.70mm *9.5mm

●质保                                                    STD.3年/IND.5年

容量

0℃ ～ 70℃

-40℃ ～ +85℃

8G

SR2SF008G-JACSC-UFE(USE)

WR2SF008G-JAISI-UFE(USE)

16G

SR2SF016G-JACSC-UFE(USE)

WR2SF016G-JAISI-UFE(USE)

32G

SR2SF032G-JACSC-UFE(USE)

WR2SF032G-JAISI-UFE(USE)

64G

SR2SF064G-JACSC-UFE(USE)

WR2SF064G-JAISI-UFE(USE)

128G

SR2SF128G-JACSC-UFE(USE)

WR2SF128G-JAISI-UFE(USE)
